IPLINE

Item code: 86.L004.2301.02

Product type: Indoor
Category: Linear Systems
Family: IPLINE
Subfamily: IPLINE

Description

Lavov linear system from the family IPLINE with a power of 46W and an optics 107.7 degrees beam angle. CCT 3000. CRI 80. IP65.

Technical description

Lavov linear system from the family IPLINE with a power of 46W and an optics 107.7 degrees beam angle. CCT 3000. CRI 80. IP65. opal diffuser . UGR22. With a total lumen output of 4153lm and an efficacy of 90.3lm/W . Made in Extruded Aluminium and finished in Black color. ON-OFF driver.

Materials

Extruded Aluminium

Installation instructions

difusor opal

Product

Real power (W)

46

Real luminous flux (Lm)

4153

Luminous efficiency (Lm/W)

90.3

Beam angle (º)

107.7

Life time (h)

50000h L80B10

IP

65

Colour

Black

U. G. R

22

Equipment

Control gear included

Yes

Control gear

ON-OFF

Dimensions

Product dimensions (mm)

L1841mm×W50mm×H80mm

Light Source

Light source

LED

Type of LED

SMD

Average life time (h)

50000h L80B10

Colour temperature (K)

3000

Colour consistency (SDCM)

SDCM<3

CRI

80

Scheme

86.L004.2301.**-scheme-01
