SLINER

Item code: 86.LR01.1303.02

Product type: Indoor
Category: Linear Systems
Family: SLINER

Description

Lavov linear system from the family SLINER with a power of 15W and an optics 110 degrees beam angle. CCT 3000. CRI 80.

Technical description

Lavov linear system from the family SLINER with a power of 15W and an optics 110 degrees beam angle. CCT 3000. CRI 80. PC Diffuser. UGR22. With a total lumen output of 2000lm and an efficacy of 133lm/W . Made in Extruded Aluminium and finished in Black color. DALI driver.

Materials

Extruded Aluminium

Installation instructions

Difusor PC

Product

Real power (W)

15

Real luminous flux (Lm)

2000

Luminous efficiency (Lm/W)

133

Beam angle (ยบ)

110

Life time (h)

50000h L80B10

IP

20

Colour

Black

U. G. R

22

Equipment

Control gear included

Yes

Control gear

DALI

Dimensions

Product dimensions (mm)

Hole size 606xW50mm

Light Source

Colour temperature (K)

3000

Colour consistency (SDCM)

SDCM<3

CRI

80

Scheme

86.LR01.1303.**-scheme-01
