IPLINE

Item code: 86.L004.1401.03

Product type: Indoor
Category: Linear Systems
Family: IPLINE
Subfamily: IPLINE

Description

Lavov linear system from the family IPLINE with a power of 31W and an optics 107.7 degrees beam angle. CCT 4000. CRI 80. IP65.

Technical description

Lavov linear system from the family IPLINE with a power of 31W and an optics 107.7 degrees beam angle. CCT 4000. CRI 80. IP65. opal diffuser . UGR22. With a total lumen output of 2936lm and an efficacy of 94.7lm/W . Made in Extruded Aluminium and finished in silver grey color. ON-OFF driver.

Materials

Extruded Aluminium

Installation instructions

difusor opal

Product

Real power (W)

31

Real luminous flux (Lm)

2936

Luminous efficiency (Lm/W)

94.7

Beam angle (º)

107.7

Life time (h)

50000h L80B10

IP

65

Colour

silver grey

U. G. R

22

Equipment

Control gear included

Yes

Control gear

ON-OFF

Dimensions

Product dimensions (mm)

L1232mm×W50mm×H80mm

Light Source

Light source

LED

Type of LED

SMD

Average life time (h)

50000h L80B10

Colour temperature (K)

4000

Colour consistency (SDCM)

SDCM<3

CRI

80

Scheme

86.L004.1401.**-scheme-01
