EASY

Item code: 86.D001.1301.01

Product type: Indoor
Category: Downlights
Family: EASY

Description

Lavov downlight from the family EASY with a power of 10W and a beam angle of 100. Finished in White colour. Dimensions ø90x46mm.

Technical description

Lavov downlight from the family EASY with a power of 10W and a beam angle of 100. Finished in White colour. Dimensions ø90x46mm.With a total lumen output of 1130lm and a luminous efficacy of 113lm/W. Made in Die Cast Aluminum. Driver ON/OFF. CCT 3000K.

Materials

Die Cast Aluminum

Optical system

Reflector

Product

Real power (W)

10

Real luminous flux (Lm)

1130

Luminous efficiency (Lm/W)

113

Beam angle (º)

100

Life time (h)

50000 h L80B10

IP

20

Electrical class insulation

Clas II

Colour

White

Equipment

Control gear included

Yes

Control gear

ON/OFF

Flicker Free

Yes

Dimensions

Product dimensions (mm)

ø90x46mm

Light Source

Light source

LED

Type of LED

SMD

Colour temperature (K)

3000

Colour consistency (SDCM)

SDCM<3

CRI

80

Scheme

86.D001.1301.xx-scheme-01
